Characteristics
|
Values
|
Type of Yarn
|
Polyester
|
Thread Count
|
9×9
|
Yarn dtex
|
1000×1000 denier/high tenacity
|
Type of Coating
|
PVC
|
PVC Backing film liner
|
75um/3mil
|
Weight (without backing film)
|
255gsm (7.5oz/yd²)
|
Total Weight
|
355gsm (10.5oz/yd²)
|
Air-flow through rates
|
|
Regular Width
|
1.60,2.0,2.20,2.50,2.80,3.20meters(126'')/
5 meters (197'') if without liner
|
Tensile Strength (warp/weft)
|
1100×1000 N/5cm
|
Tear Strength (warp/weft)
|
250×200 N
|
Flame Resistance
|
NFPA701,M2,B1,B2
(customized by requests)
|
Low Temperature (No crack at:)
|
-30℃ （-22°F）
|
RF Weldable (Heat Sealable)
|
Yes
|
